Steel Structure Design for EHV Substations:
In EHV outdoor Switchyards, to create sufficient ground clearance and phase to earth clearance, the live conductor heights from ground needs to be increased with the help of steel structures. Gantry Towers and beams are lattice type structures and equipment support structures are either lattice type or pipe type structures. These structures are designed as per Indian standard (IS) 800 or 802 by using staad pro software.
Satcon has very rich expertise of more than two decades in Steel structures designs for EHV substations for utilities and renewable energy projects. Such designs are delivered for overseas projects as well. For overseas projects, the designs are done as per relevant Eurocode or ASCE standard.
